Diamondback line of sight hydraulic hose sleeve

Standard Diamondback hydraulic hose sleeve with line of sight

Line-of-Sight hydraulic hose sleeve

Pinhole, Burst Protection, & Abrasion Protection

Diamondback Standard

The Diamondback L.O.S. sleeve features a line-of-sight indicator to ensure operators stay a safe distance away from any hydraulic hose failure. It also shields hoses from constant environmental abrasion, sun and heat damage, and dangerous pinholes and leaks. Made from a proprietary engineered fiber woven tightly and heat-treated to fit the hose perfectly, it's a go-to choice for construction and heavy equipment applications. The Diamondback meets the EU Machinery Directive 2006/42/EC and the NSW Guideline for Fluid Power System Safety at Mines.

Tested over 1.7 million abrasion cycles (ISO 6945)
Meets "Line of Sight" operator protection specification EN982, EN414, EN ISO Regulation 3457:2008
Temperature tested to 200°F continuous, 350°F intermittent

Pinhole protection tested to 4,000 PSI, burst protection tested to 12,000 PSI
Cut to length; 50% less bulky than Cordura
Sleeve dispensers available for quick measurement

Meets conductivity standard ISO 8031
Mine Safety and Health Administration (MSHA) approved IC-289/01
Tight, smooth surface contains oil spillage from pinhole leaks

Abrasion Resistance

− − − −

Puncture Resistance

− − − −

Chemical Resistance

− − − −

UV Protection

− − − −

Non-wicking Ability

− − − −

Spark / Spall Protection

− − − −

Weight Flexibility

− − − −

Temperature Rating

− − − −

DIAMONDBACK

LITE

Economical
UV Protection
Abrasion Resistant

DIAMONDBACK

STANDARD

Economical
UV Protection
Abrasion Resistant
Line-of-Sight Burst Protection

DIAMONDBACK

PRO

Close up of Diamondback Pro Sleeve Material

Economical
UV Protection
Abrasion Resistant
Line-of-Sight Burst Protection
Easy Operator Installation

The best hydraulic hose protection

Hydraulic hose failures are a serious hazard to both equipment and operators. The Diamondback L.O.S. is built to address that — providing line-of-sight operator protection, burst and pinhole containment, and abrasion resistance all in one sleeve.

With nearly 6x the abrasion resistance of competitive samples (ISO 6945) and burst protection tested to 12,000 PSI, the Diamondback delivers serious protection without the bulk.

DIAMETER (IN)	ITEM #	FLAT WIDTH (IN)	ROLL LENGTH (FT)
0.67"	DBK-017	1.18"	300
0.79"	DBK-020	1.34"	300
0.91"	DBK-023	1.54"	300
0.98"	DBK-025	1.65"	300
1.06"	DBK-027	1.77"	300
1.22"	DBK-031	2.05"	300
1.42"	DBK-036	2.24"	300
1.57"	DBK-040	2.6"	300
1.73"	DBK-044	2.83"	300
1.85"	DBK-047	3.03"	300
2.17"	DBK-055	3.5"	300 (TWO 150FT ROLLS)
2.36"	DBK-060	3.82"	300 (TWO 150FT ROLLS)
2.62"	DBK-066	4.18"	300 (TWO 150FT ROLLS)
2.87"	DBK-073	4.65"	300 (TWO 150FT ROLLS)
3.14"	DBK-080	5.02"	300 (TWO 150FT ROLLS)
3.66"	DBK-093	5.87"	300 (TWO 150FT ROLLS)
3.94"	DBK-100	6.3"	300 (TWO 150FT ROLLS)
4.41"	DBK-112	7.05"	300 (TWO 150FT ROLLS)

WIDTH (IN)	ITEM #	ID	DESCRIPTION
¼”	BC-1.75	1.75	Band Clamp 1.75” Dia
¼”	BC-2.25	2.25	Band Clamp 2.25” Dia
¼”	BC-3.25	3.25	Band Clamp 3.25” Dia

Line-of-Sight hydraulic hose sleeve

Pinhole, Burst Protection, & Abrasion Protection

Diamondback Standard

Features & Benefits

Material Attributes

Abrasion Resistance

− − − −

Puncture Resistance

− − − −

Chemical Resistance

− − − −

UV Protection

− − − −

Non-wicking Ability

− − − −

Spark / Spall Protection

− − − −

Weight Flexibility

− − − −

Temperature Rating

− − − −

WHAT'S THE DIFFERENCE?

The best hydraulic hose protection

SIZING & ORDERING INFORMATION

Band Clamps Ordering Information
